S1D15K01(Hybrid LCD Driver)

Sales & Support

The S1D15K01 is a Hybrid LCD Driver IC that can be directly connected to a microcontroller, enabling Segment and Dot matrix display can be simultaneously displayed on a single LCD panel. The dedicated drive circuits for segment and dot matrix are mounted on a single chip, eliminating display defects caused by the difference in drive voltage between the segment area and dot matrix area, realizing high contrast display, and contributing to module cost reduction. The S1D15K01 also has a built-in temperature sensor circuit. This allows the system to be configured for optimal LCD contrast over a wide temperature range.

In addition, this product meets the stringent quality requirements for automotive applications, with an operating temperature of up to 105 ℃ and AEC-Q100 corresponsive.

Features

Hybrid LCD can be driven by a single chip （Segment：120 x 4　Dot Matrix：160 x 80）
Built-in Temperature Sensor Circuit

Outline Specifications

Part Number	S1D15K01
Supply Voltage	System VDD to VSS: 3.0 V～5.5 V
Supply Voltage	Booster VDD to VSS: 3.0 V～5.5 V
MPU Interface	3-wire Serial Interface
LCD Driver	Segment： 120 x 4　　Dot Matrix：160 x 80
LCD Drive Duty Configuration	Segment： 1/4 ～ 1/1
LCD Drive Duty Configuration	Dot Matrix：Max 1/80
LCD Drive Bias Configuration	Segment： 1/3 (1/4 duty ～ 1/2 duty), static (1/1 duty)
LCD Drive Bias Configuration	Dot Matrix：1/5 to 1/13 (APT, IAPT conversion) Variable with electronic volume
Error Detection Functions	Detection of bit corruption in command register
Error Detection Functions	RAM for Dot Matrix operation status error detection　etc.
Automotive QA	AEC-Q100
Operating Temperature Range	－40～＋105℃
Others	Built-in Oscillation Circuit
Others	Built-in Temperature Sensor Circuit
Briefsheet
Shipment Form	Au Bump Chip

This IC is not designed for complying with radiation- or light-protected design.
